BDP-1500 Explosion-Proof Liquid Filling Machine
Model：BDP-1500
Product Features
Product Features
- The BDP-1500 explosion-proof liquid filling machine is a fully customized product, designed according to customer needs by a professional filling machine manufacturer.
- The control box has TS explosion-proof certification and is suitable for ZONE 1&2 and ZONE 21&22 hazardous locations. (Taiwan standard EX compatible)
- 100% developed and manufactured in Taiwan, the weighing control indicator BDI-2006 can record 100 groups of data. Simply recall the corresponding group of the product to start one-day production.
- The size of the customized scale platform is 1500cm × 1800cm, and the scale surface is made of stainless steel #316. It can directly place a 1000-liter chemical barrel (IBC barrel) or a pallet carrying four 53-gallon barrels.
- Special barrel filling machine valve for liquids made of stainless steel #316, Teflon stainless steel wire braided pipe, with high acid and alkali resistance and anti-sticking properties.
- Customize the filling valve swing arm and the forward and backward moving module to change the corresponding position of the barrel filling machine valve, which is suitable for one-time filling of 4 barrels and 53-gallon barrels on the pallet.
| Customer needs |
| Suitable for irritating or corrosive liquids, and some products are hazardous liquids. |
| No need conveyors, and the filling equipment can be used for 53-gallon barrels and 1000-liter IBC barrels. Transporting by fork lifter. |
| Improve Efficiency |
| Supports both filling specifications of 53-gallon barrels and 1000-liter IBC barrels, and meets the limitations of customer-controlled work areas. |
| Depending on the characteristics of the customer's filling products, a 1,000-liter IBC barrel can fill up to 160 barrels a day, and a 53-gallon barrel can fill up to 720 barrels, which shortens production time and greatly increases output. |
| Improve product filling accuracy, ensure product shipping weight, maintain product quality consistency, and reduce after-sales communication costs. |
| The equipment complies with TS explosion-proof certification, which improves the safety of personnel and equipment and reduces the risk of loss in accidents. |
Product Specifications
| Model | BDP-1500 |
| Range | 100 ~ 1500 kg |
| Accuracy | ≦0.2%F.S |
| Speed | 20 ~ 90 brrrel / hr |
| Type | One time one nozzle / 4 |
| Nozzle | SUS316 / PTFZ |
| Hose | DN2 / Open |
| CPS | 0.25 ~ 500 |
| BARREL | IBC / 53 gallon × 4 |
